使用：Interior cladding, walls, and partitions

应用程序：Residential, commercial, institutional

特征:Medium Density Fibreboard (without formaldehyde), laser-cut, individual designs possible (send a DXF/DWG file), 70 patterns to choose from

大小:Format Raw Material: 10x2800x2070mm, 19x5600x2070, 30x5600x2070 / Maximal Format Industrial Coating: 5600mm x 1300mm / Thickness: 10, 19 or 30mm

认证:Fire properties: B2, B1 with additional coating

More about this product

Bruag offers laser-cut perforated panels made from Medium Density Fibreboard (MDF). The degree of detail in perforations are excellent compared to traditional production techniques such as CNC.

Laser Technology

Bruag laser technology offers creative-minded designers maximum flexibility providing the opportunity to create extremely delicate perforated panels for different wall cladding applications.

New interpretations of historic patterns or completely new ornamentations and perforations that have never previously been seen can be produced in almost any dimension using digital input information (dxf, dwg).

Colors：In addition to the flexibility regarding panel shapes, a wide range of colors can be specified. A choice of over 3000 different colors (RAL, NCS S, Bruag Alu, Les Couleurs® Le Corbusier) is available.

Les Couleurs® Le Corbusier

The world-renowned Swiss Architect Le Corbusier not only left behind a great architectural heritage but his own color system, too. Les Couleurs® Le Corbusier is a coherent system of 63 architectural colors, where all colors are naturally harmonious and can be combined with each other.

Features and Benefits：Totally individual forms (incl. perforations and ornaments) possible、Robust、Large choice of colors、Wall Cladding is an excellent cladding system for interior spaces. Made of medium Density Fibreboard (without formaldehyde) and cut by laser. Wall cladding acoustics are enhanced by the perforations.

Application and Use in Construction：Walls, Interior, Partitions

Type of Material：Wood-based panels

Format：Slabs / Plates / Panels

关于这个产品的更多信息

布鲁格提供激光切割穿孔板制成的中密度纤维板(MDF)。与传统的生产技术如CNC相比，射孔的细节程度是非常好的。

激光技术

布鲁格激光技术为富有创造力的设计师提供了最大的灵活性，为不同的墙壁覆盖层应用提供了创建极其精致的穿孔板的机会。

使用数字输入信息(dxf, dwg)，几乎可以在任何维度上对历史图案进行新的诠释，或生成以前从未见过的全新纹饰和穿孔。

颜色:除了面板形状的灵活性之外，还可以指定多种颜色。可选择超过3000种不同的颜色(RAL, NCS S, Bruag Alu, Les Couleurs®Le Corbusier)。

Les Couleurs®Le Corbusier

世界著名的瑞士建筑师勒·柯布西耶不仅留下了伟大的建筑遗产，也留下了自己的色彩系统。Les Couleurs®Le Corbusier是一个由63种建筑色彩构成的连贯系统，所有的色彩都是自然和谐的，可以相互结合。

特点和好处:完全独立的形式(包括穿孔和装饰)可能的，稳健的，大量的颜色选择，墙壁覆盖是一个优秀的内部空间覆盖系统。由中密度纤维板(不含甲醛)经激光切割而成。墙面覆盖的声学效果通过穿孔得到了增强。

在建筑工程中的应用和使用：墙壁,室内,分区

类型的材料：木基板

格式：厚板/盘子/镶板
